SHBN type wireless nut runner
High-speed, lightweight, high-precision tool
- Impact mode
Impact automatic adjustment function
Batch count function
- Reliable transfer of tightening data
- No need to wait for connection when replacing the battery
- Power saving tightening tool
- Various tightening functions
- Double tool count
- Tool LED supports workers
- Multiple tools can be controlled
- High-performance station controller
Large-capacity tightening history memory
USB backup function
Supports LAN connectionFrom the USB port, you can back up the tightening settings, history, etc. to the USB memory.
Compatible with various communication networks
Station controller terminal (SCT).
|Maximum tightening torque||16N · m (impact mode)|
|Maximum no-load rotation speed||2000rpm|
|Wireless specifications||Wireless LAN 2.4GHz|
|weight||1.2kg (excluding battery)|
|interface||I / O (8 points each for input and output) x 2 ports (up to 4 ports
depending on the option ) RS232C x 2 ports ( up to 4 ports depending on the option)
USB x 2 ports
Ethernet x 1 port
Field network (option)
|Power supply||AC100 ~ 240V 50 / 60Hz (AC adapter)|
|Maximum power consumption||360W|
|charging time||80% or more in about 60 minutes|
|Protective function||Overcharge prevention|
|Display function||LED display (3 colors / 6 levels)|
|Power supply||AC100 ~ 240V 50 / 60Hz|
* Please contact us for the details of the product model.
Pistol tool (SHB-T1-016P)
Station controller (SHB-SC)
International automotive news wrote an article about the new Sanyo handheld nutrunner.
Following is our translation of the Japanese article.
Sanyo, started selling new nutrunner in the US
and develops nutrunner fastening tools for automotive industries,
has proudly announced to sell a new handheld nutrunner model in the US market.
They had been selling 10Nm and 20Nm pistol tools, straight tools, and angle tools already,
addition to that they had added a new 16Nm type handheld nutrunner [SHDN-T2-016P] that was developed to satisfy customer requests.
This tool has achieved the top rated speed and is very light in weight (under 1kg).
The subsidiary company in the US, Sanyo Machine America Corp. is planning to sell $400,000 of this nutrunner in 2018.
They are going to enrich local support & repair structure in the US, and are planning to increase share in the US handheld fastening market.
Sanyo has been awarded for the supplier special recognition award from
American Honda this past June, and has been awarded the supplier of the year award on 2015.
